Background of Transformer EMF Equation DerivationWhen a sinusoidal voltage is applied to the transformer's primary winding, an alternating flux ϕmis induced in the iron core. This sinusoidal flux links both primary and secondary windings, with its functional form described by a sine function.Mathematical Derivation of Flux Rate of ChangeThe following outlines the derivation of the transformer's EMF equation, with defined parameters:ϕm: Maximum flux (Weber)f: Supply frequency (Hz)N1: Number of pr

Transformer Resistance and Reactance RepresentationResistance DefinitionThe resistance of a transformer refers to the internal resistance of its primary and secondary windings, denoted as R1 andR2. Corresponding reactances are X1 andX2, withKrepresenting the transformation ratio. To simplify calculations, impedances can be referred to either winding—either primary terms referred to the secondary side or vice versa.Voltage Drops in WindingsResistive and reactive voltage drops in primary and

AC Circuit FundamentalsAn AC circuit is defined as a circuit energized by an alternating power source. Alternating current (AC) is widely used for domestic and industrial applications due to its unique characteristics: unlike DC, both the magnitude and direction of current and voltage in an AC circuit vary periodically over time.AC waveforms typically follow a sinusoidal pattern, completing one cycle with equal positive and negative halves. This behavior is mathematically described as a function

Definition of Peak ValueThe peak value of an alternating quantity refers to the maximum magnitude it reaches within one cycle. Also known as the maximum value, amplitude, or crest value, this parameter for a sinusoidal quantity occurs at 90 degrees, as illustrated in the figure below. Peak values of alternating voltage and current are denoted by Em andIm, respectively.Average Value of Alternating QuantitiesThe average value of an alternating voltage or current is defined as the mean of all insta

Star Connection in Three-Phase SystemsIn a star (Y) connection, the similar ends (either starts or finishes) of the three windings are joined at a common point called the star or neutral point. The three line conductors extend from the remaining free terminals to form the phase connections.For a three-phase, three-wire system, only the three line conductors are connected to the external circuit. Alternatively, a four-wire system includes a neutral conductor drawn from the star point, as illustra

Plugging (Reverse Current Braking) in DC MotorsIn plugging (reverse current braking), the armature terminals or supply polarity of a separately excited or shunt motor is reversed while the motor is running. This causes the supply voltageV and the induced back EMFEb to act in the same direction. Consequently, the effective voltage across the armature during plugging becomesV + Eb—nearly double the supply voltage—reversing the armature current and generating high braking torque. An ext

Coil Span Factor (Pitch Factor) Definition and CharacteristicsDefinition of Pitch Factor (Kₙ)The coil span factor (also known as the chording factor) Kₙ is defined as the ratio of the induced voltage in a short-pitched coil to that in a full-pitched coil. The distance between the two sides of a coil is termed thecoil span, which is characterized by its electrical angle to indicate the degree of short-pitching.Physical Meaning of Pole PitchThe angular distance between the central lines of adjacen

Synchronous Reactance and Impedance PrinciplesSynchronous reactance (Xₛ) is an imaginary reactance used to represent voltage effects in the armature circuit, arising from both the actual armature leakage reactance and air gap flux variations due to armature reaction. Similarly, synchronous impedance (Zₛ) is a fictitious impedance that accounts for voltage effects from the armature resistance, leakage reactance, and air gap flux changes caused by armature reaction.The actual generated voltage com

The Constant Flux Linkage Principle in Alternator TransientsThe constant flux linkage concept is fundamental to analyzing alternator transients. It states:In a closed circuit with zero resistance and capacitance, flux linkages remain unchanged following a sudden disturbance, preserving their pre-disturbance values.In alternators, armature and field windings exhibit negligible capacitance, and their resistances are insignificant compared to inductances. Thus, these windings can be treated as pure

Resistance SwitchingResistance switching refers to the practice of connecting a fixed resistor in parallel with the contact gap or arc of a circuit breaker. This technique is applied in circuit breakers with high post-arc resistance in the contact space, primarily to mitigate re-striking voltages and transient voltage surges.Severe voltage fluctuations in power systems arise from two main scenarios: interrupting low-magnitude inductive currents and breaking capacitive currents. Such overvoltages
